Scientific Doors

Name: Scientific Doors
Brand: ASK GROUP
Price: 3400.0 INR
Availability: InStock

Price 3400.0 INR/ Square Foot

Get a Price/Quote

MOQ : 1 Piece

Scientific Doors Specification

Anti Corrosion
Yes

Usage & Applications
Research Laboratories, Pharma Units, Clean Rooms

Thickness
40 mm

Coating Type
Epoxy

Weather Resistance
Yes

Operation Type
Manual Hinged

Capacity
Single / Double Leaf

Width
800 mm

Operating Temperature
Up to 60C

Standard
GMP / ISO 14644 / cGMP

Load Capacity
Standard

Security Features
Fire Resistant, Sound Insulation

Function
Air Tight, Dust Proof, Contaminant Control

Mesh Type
Without Mesh

Finish Type
Powder Coated / Epoxy Painted

Height
2100 mm

Glass Thickness
6 mm

Glass Type
6 mm Toughened Glass

Tensile Strength
High

Surface Finish
Smooth

Product Type
Clean Room Door

Material
Stainless Steel

Size
Different Available

Weight
25 Kilograms (kg)

Color
Off White

Application
Commercial

Mounting Type
Wall Mounted

Design Type
Solid Panel with Vision Panel

Window Type
Fixed Glass Vision Panel

Product Model
SD-GI-01

Installation Type
Flush Mounted

Locking Type
SS Mortise Lock with Key

Sound Reduction Rating
Up to 32 dB

Hinge Type
Concealed Stainless Steel Hinges

Edge Profile
Square / Rounded

Hardware
Door Closer, Lever Handle, Kick Plate Available

Vision Panel Size
400 mm x 600 mm (Standard)

Frame Material
Stainless Steel 304 / GI

Door Opening Direction
Left or Right Hinged as Required

Fire Rating
Up to 120 Minutes

Panel Core
Honeycomb Kraft Paper / Rockwool

Sealing System
Silicon Gasket

Scientific Doors Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
100 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
South India

About Scientific Doors

Scientific doors, also known as cleanroom or hygienic doors, are specialized entry systems engineered for controlled environments in laboratories, pharmaceutical facilities, biotechnology labs, and research centers. Constructed from non-porous materials like stainless steel, galvanized iron, or fiber-reinforced plastic (FRP), they feature seamless, flush designs to prevent bacterial accumulation, dust ingress, and contamination.

These doors withstand frequent chemical cleaning, resist corrosion, and often include vision panels, airtight seals, and interlocking mechanisms to maintain positive pressure and sterility. They comply with standards such as GMP, FDA, and ISO 14644, ensuring hygiene in sensitive applications like drug manufacturing or semiconductor production.

Precision Engineering for Controlled Environments

These scientific doors are designed to support contaminant control and ensure maximum air tightness-vital for laboratories, pharma units, and clean rooms. They incorporate a silicon gasket sealing system, offering high weather resistance and preventing unwanted air or particulate ingress, supporting your project's compliance and sterility requirements.

Durable Construction with Safety Features

Built with stainless steel 304 or GI frames and concealed stainless steel hinges, our doors offer robust durability. The honeycomb kraft paper or rockwool panel core delivers both sound insulation (up to 32 dB) and fire resistance (up to 120 minutes), ensuring the safety of people and equipment in high-risk environments.

Flexible Installation and User-Friendly Operation

Available in different sizes and opening directions (left or right hinged), the doors come with a manual operation system and flush-mounted installation. The smooth powder-coated or epoxy finish resists corrosion and is easy to maintain, while accessories like door closers, lever handles, and kick plates further enhance convenience and longevity.

FAQ's of Scientific Doors:

Q: How can I determine the correct hinge direction for installation?

A: The doors can be configured as either left or right hinged, as required by your site layout or operational workflow. At the time of ordering, specify the opening direction to ensure seamless integration into your facility.

Q: What materials are used for the frame and core of these doors?

A: Frames are manufactured from high-grade Stainless Steel 304 or GI, while the panel core can be either honeycomb kraft paper or rockwool, providing strength, sound insulation, and fire resistance.

Q: When is it beneficial to use these scientific doors in my facility?

A: These doors are ideal for environments where stringent air tightness, contaminant control, and fire/sound resistance are essential, such as research laboratories, pharmaceutical production units, and clean rooms.

Q: Where are these doors typically installed?

A: They are commonly flush-mounted onto walls in commercial and controlled environments, including laboratories, pharma units, and any space requiring enhanced hygiene and security.

Q: What is the process for ordering and customizing the door size or finish?

A: During the inquiry or ordering phase, you can specify dimensions, hinge direction, core type, finish (powder coated or epoxy painted), and accessories. Customizations are available to fit a variety of wall openings and design preferences.

Q: How does the silicon gasket sealing system benefit users?

A: The silicon gasket offers superior sealing, making the doors airtight and dust-proof. This inhibits cross-contamination, maintains pressure differentials, and helps comply with regulatory requirements in controlled environments.

Q: What are the main benefits of using this door model over standard doors?

A: This model combines fire resistance, sound insulation, high durability, anti-corrosion features, and regulatory compliance (GMP, ISO 14644, cGMP) in one seamless solution, making it preferable for critical environments where safety and cleanliness are paramount.
